MFH-5-1/4 6211 Solenoid valve MFH Series Tiger valve
Air solenoid valve MFH-5-1/4
Part number: 6211
| Model | MFH-5-1/8 MFH-5-1/4 |
| Type | 5/2 way |
| Effective section area | 22.5mm2(CV=1.32) |
| Port size | 1/8",1/4" |
| Filter precision | 40 micron filtered air |
| Operation | Internal piloted |
| Working pressure | 0.25-1.0MPa |
| Max.pressure | 1.2MPa |
| Temperature | 5~50 degrees centigrade |
| Voltage range | Plus or minus 10% |
| Power consumption | AC:5.5VA, DC:4.8W |
| Protection | F Class. IP65 |
| Wiring/Connector | Lead wire or DIN connector |
| Switching frequency | 5 cycles/sec |
| Response time | 0.05 sec |
| Standard voltage | DC12V, DC24V, AC24V, AC36V,AC110V, AC220V, AC380V |
Features:
(1)Large flow
Featured flow at 1300L/min(Cv=1.32), meet the demand of large bore
and long stroke cylinder.
(2)Low requirement quailty of air filteration
Coxial structure design with better dust resistance function than
spool type valve
(3)Reliable quality sealing with longer durability
Coxial structure design avoids direct friction between seal and
valve body,
Significantly increases the life of seal and valve body.
Seal material is polyurethane to ensure better durability.
