Electro-Pneumatic Positioner YT-1000R used for operation of
pnuematic rotary valve actuators
Ordering code
Description
The Electro-Pneumatic Positioner YT-1000R is used for operation of
pnuematic rotary valve actuators by
means of electricalcontroller or control system with an analog
output signal of DC 4 to 20mA or split ranges.
Demension
Specifications
| ltem . Type | Single | Double |
| Input Signal | 4-20mA DC |
| Impedance | 250 ± 15 Ω |
| Supply Pressure | 0.14~0.7MPa(1.4~7 bar) |
| Stroke | 0~ 90° |
| Air Connection | PT(NPT) 1/4 |
| Gauge Connection | PT(NPT) 1/8 |
| Conduit | G(PF,NPT)1/2, M20 |
| Explosion Proof | Ex dmb IlB T5 (KTL) |
| Ex dmb IlC T5 (KTL) |
| Ex ia IlB T6 (KTL) |
| Ex ia IlC T6 (NEPSI) |
| Ex dmb IIC T5/T6 (NEPSI) |
| Enclosure | IP66 |
| Ambient Temp. | Operating: -20℃~70℃(-4~158℉) |
| Explosion: -20℃~60℃(-4~140℉) |
| Linearity | ± 1% F.S. | ± 2% F.S. |
| Hysteresis | ± 1% F.S. |
| Sensitivity | ± 0.2% F.S. | ± 0.5% F.S. |
| Repeatability | ± 0.5% F.S. |
| Air Consumption | 2.5LPM (sup=0.14MPa) |
| Flow Capacity | 80LPM (sup=0.14MPa) |
| Material | Aluminum Diecasting |
| Weight | 2.8kg (6.2 Ib) |
